Linear Encodeur Scale 150LPI - L5000 - W15
✔️ Type: Linear encoder scale (150 LPI, 5000 × 15 mm)
✔️ OEM ref: —
✔️ Precise measurement of a linear axis position
✔️ Compatible: Fujifilm Acuity, Mimaki SWJ, Mimaki UJV55
✔️ Brand: DG Spare Parts
-
New or refurbished at the best price
-
Fast shipping within 24 hours
-
Worldwide delivery
Product description
Linear Encoder Scale 150 LPI (5000 × 15 mm) Mimaki/Fujifilm – L5000-W15
The Linear Encoder Scale 150 LPI (5000 × 15 mm) is an optical encoder strip that replaces Mimaki MP-E301184 on SWJ-320, UJV55-320 and Fujifilm Acuity 3200 LED printers.
It measures the carriage or axis position precisely and can be trimmed to fit smaller machines.
Technical specifications
- OEM reference: —
- Manufacturer: DG Spare Parts
- Part type: Linear encoder scale (150 LPI, 5000 × 15 mm)
- Resolution: 150 LPI
- Size: 5000 mm × 15 mm
- Equivalent reference: MP-E301184 (replaces)
- Shipping: Shipped ready to install
Compatibility & use
- Fujifilm Acuity
- Mimaki SWJ
- Mimaki UJV55
Function
- Precise measurement of a linear axis position
- Controls the carriage or gantry positioning
- Synchronises the machine movements
Signs of wear
- Positioning errors
- Print offset
- Loss of movement precision
- Axis sensor error messages
Replacing this part restores the machine to proper working order.
♻️ DG Spare Parts – European specialist in spare parts for large-format printers and plotters.
Compatibility
| Compatible with Mimaki® | Mimaki SWJ-320Mimaki UJV55-320 |
|---|---|
| Compatible with Fujifilm® | Fujifilm Acuity 3200 LED |
