B4H70-67005 - Edge holder

EDGE HOLDER

The Edge Holder, part number B4H70-67005, is the media edge holder fitted to the print deck of HP Latex 100/300 and 500 series printers. It is sold individually: the machine uses one on each side of the substrate.

This part plays a critical technical role in the machine’s operation. Replacing it restores the equipment to its original performance.

Component function

• Holds the edge of the substrate flush against the
print platen• Prevents the edge from lifting or curling, which causes contact with the print heads•
Ensures the safe loading and feeding of difficult media: thin films, warped substrates,
textiles• Folds back into the parking position when not in use, without needing to be removed from the machine

Part numbers

OEM part number: B4H70-67005
OEM designation: Edge holder
Packaging: sold individually

Machine compatibility

• HP Latex
110• HP Latex
115• HP Latex
310• HP Latex
315• HP Latex
330• HP Latex
335• HP Latex
360• HP Latex
365• HP Latex
370• HP Latex
375• HP Latex
560• HP Latex 570

Important technical information

• Type: media edge holder,
substrate feed area• OEM part number:
B4H70-67005• Packaging: 1 unit•
Location: print deck, left or right side of the substrate•
Installation:
tool-free installation and folding into parking position• Check: check its position before each
media load• Weight: 0.1 kg

Possible symptoms in the event of a fault

• The edge of the media lifts up and rubs against the print heads•
Ink streaks, smudges or print head crashes at the edge of the media•
Repeated jams when loading thin or
warped media• Retainer cracked, deformed or missing following a carriage incident
