Linear Encoder Scale 180LPI - L4500 - W15
- Out-of-Stock
✔️ Type: Linear encoder scale (180 LPI)
✔️ OEM ref: L4500-W15
✔️ Serves as the position reference for the encoder
✔️ Compatible: Dilli Neo Plus UVP, Dilli Neo Titan UVT, Dilli Neo Venus UVV (+29 series)
✔️ Brand: DG Spare Parts
-
New or refurbished at the best price
-
Fast shipping within 24 hours
-
Worldwide delivery
Product description
L4500-W15 – Linear encoder scale 180 LPI (Linear Encoder Scale) – multi-brand
The L4500-W15 linear encoder scale 180 LPI (Linear Encoder Scale) is fitted to a wide range of large-format printers.
It serves as the position reference for the encoder sensor for the precise positioning of the carriage along the axis. A scratched or soiled scale causes banding.
Wide compatibility: many Mimaki (CJV30/JV3/JV4/JV5/JV33/TS3/TS5), Roland (SJ/SC/FJ/VS/XC/XJ), Mutoh Cobra and Dilli Neo Plus/Titan/Venus printers.
Technical specifications
- OEM reference: L4500-W15
- Manufacturer: DG Spare Parts
- Part type: Linear encoder scale (180 LPI)
- Shipping: Shipped ready to install
Compatibility & use
- Dilli Neo Plus UVP
- Dilli Neo Titan UVT
- Dilli Neo Venus UVV
- Mimaki CJV30
- Mimaki JV2
- Mimaki JV3
- Mimaki JV3-75 SP II
- Mimaki JV3-130SP II
- Mimaki JV4
- Mimaki JV5
- Mimaki JV33
- Mimaki PV
- Mimaki TS3
- Mimaki TS5
- Mutoh Cobra S100UV
- Roland AJ
- Roland CJ
- Roland FJ
- Roland FLJ
- Roland FP
- Roland LEC
- Roland LEJ
- Roland RA
- Roland RE
- Roland RS
- Roland SC
- Roland SJ
- Roland SP
- Roland VP
- Roland VS
- Roland XC
- Roland XJ
Function
- Serves as the position reference for the encoder
- Enables the precise positioning of the axis or media
- Key component of the print accuracy
Signs of wear
- Position misread or lost
- Banding or offsets when printing
- Encoder errors
- Scratched or soiled scale
Replacing this part restores the machine to proper working order.
♻️ DG Spare Parts – European specialist in spare parts for large-format printers and plotters.
Compatibility
| Compatible with Mimaki® | Mimaki CJV30-100Mimaki CJV30-100BSMimaki CJV30-130Mimaki CJV30-130BSMimaki CJV30-160Mimaki CJV30-160BSMimaki CJV30-60Mimaki CJV30-60BSMimaki JV2-130Mimaki JV2-160Mimaki JV2-180Mimaki JV2-90Mimaki JV3-130SMimaki JV3-130SLMimaki JV3-130SP IIMimaki JV3-160Mimaki JV3-160SMimaki JV3-160SPMimaki JV3-250SPMimaki JV3-75 SP IIMimaki JV33-130Mimaki JV33-130BSMimaki JV33-160Mimaki JV33-160BSMimaki JV33-260Mimaki JV33-260BSMimaki JV4-130Mimaki JV4-160Mimaki JV4-180Mimaki JV5Mimaki JV5-130SMimaki JV5-160SMimaki JV5-260SMimaki JV5-320DSMimaki JV5-320SMimaki PV-130Mimaki PV-90Mimaki TS3-1600Mimaki TS5-1600AMF |
|---|---|
| Compatible with Roland® | Roland AJ-1000Roland AJ-1000iRoland AJ-740Roland AJ-740iRoland CJ-400Roland CJ-500Roland CJ-540Roland CJ-60Roland CJ-70Roland FJ-40Roland FJ-400Roland FJ-42Roland FJ-50Roland FJ-500Roland FJ-52Roland FJ-540Roland FJ-600Roland FJ-640Roland FJ-740Roland FLJ-300Roland FP-740Roland LEC-300Roland LEC-300aRoland LEC-330Roland LEC-540Roland LEJ-640Roland RA-640Roland RE-640Roland RS-540Roland SC-500Roland SC-540Roland SC-545exRoland SJ-1000Roland SJ-1045exRoland SJ-500Roland SJ-540Roland SJ-600Roland SJ-640Roland SJ-645exRoland SJ-700Roland SJ-740Roland SJ-745exRoland SP-300Roland SP-300iRoland SP-300vRoland SP-540vRoland VP-300Roland VP-300iRoland VP-540Roland VP-540iRoland VP-540vkitRoland VS-300Roland VS-420Roland VS-540Roland VS-640Roland XC-540Roland XC-540mtRoland XJ-540Roland XJ-640Roland XJ-740 |
| Compatible with Mutoh® | Mutoh Cobra S100UV |
| Compatible with Dilli® | Dilli Neo Plus UVP-2506Dilli Neo Titan UVT-1604DDilli Neo Titan UVT-1606SDilli Neo Titan UVT-1606WDilli Neo Venus UVV-2506GW |
