E102025 - photo-interrupter sensor / optical sensor

TX2-1600 Origin Sensor Assy

The TX2-1600 Origin Sensor Assy reference E102025 is a photo-interrupter sensor / optical sensor used in Mimaki roll-to-roll printers.

This component plays a critical technical role in the machine's operation. Replacing it restores the equipment's original performance.

Component Function

• Detects mechanical element position or presence
• Transmits a logic signal to the control board
• References home positions
• Secures mechanical movements

References

OEM Reference: E102025

Machine Compatibility

• Mimaki JV33

Important Technical Information

• Type : photo-interrupter sensor / optical sensor
• OEM Reference : E102025
• Brand : Mimaki
• Compatible machines : Mimaki JV33
• Installation : by qualified technician

Possible Symptoms in Case of Failure

• Position errors (origin, home) at startup
• Sudden carriage or axis stop
• Sensor error messages
• Erratic or out-of-range movements
