F/S Gantry Bearings Kit (Left + Right) – Canon Océ Arizona – 3010112732

The F/S Gantry Bearings Kit (Left + Right) – OEM part number 3010112732 – is a Field Service maintenance kit comprising the two gantry guide bearings (left and right) for Canon Océ Arizona UV flatbed printers.

On these flatbed machines, the gantry — the crossbeam that supports the print carriage — moves along the Y-axis above the print table. The bearings ensure the linear guidance of this beam along its rails, on either side of the frame. This precision guarantees smooth, play-free movement of the gantry, which is essential for the correct positioning of print passes.

Supplied as a complete set (left + right kit), it is intended for the preventative or corrective replacement of the original bearings in accordance with Canon Océ (OEM) specifications, in order to restore smooth and precise movement of the gantry.

Technical specifications

• OEM part number: 3010112732
• Manufacturer: Canon Océ (Arizona)
• Part type: Field Service (F/S) kit – bearings / gantry linear guide
• Kit contents: left bearing + right bearing (complete set)
• Axis / Area concerned: Y – gantry movement above the table
• Sub-assembly concerned: gantry (carriage beam) and guide rails
• Delivery: complete kit, ready for maintenance work
• Part type: Canon Océ original part (OEM)
• Application: large-format UV flatbed printer

Compatibility and use

• Canon Océ Arizona 400 series (4xx)
• Canon Océ Arizona 400 series (5xx)
• Canon Océ Arizona 600 series (6xx)
• Canon Océ Arizona 1200 series (12xx)
• Canon Océ Arizona 1300 series (13xx)
• Canon Océ Arizona 2200 Series (22xx)

Function

• To ensure the linear guidance of the gantry along the Y-axis
• To keep the carriage beam on its rails without any play on both sides
• Ensure smooth and precise movement of the gantry above the table
• Contribute to the mechanical stability required for printing accuracy
• To reduce friction and premature wear of the guide rails

Possible symptoms of wear

• Play or wobble in the gantry during movement
• Abnormal noises (squeaking, jerking) as the gantry passes over
• Misalignment or banding on the print (Y-axis positioning)
• Vibrations or abnormal resistance to gantry movement
• Error messages relating to movement or positioning of the Y-axis

Replacing the gantry bearings with this Field Service kit restores precise, quiet guidance, maintains print alignment and extends the service life of the machine’s rails.
