DF-43901 - linear encoder strip (T-fence) for carriage axis

T fence (16_180) assembly (encoder strip)

The T fence (16_180) assembly (encoder strip) reference DF-43901 is a linear encoder strip (T-fence) for carriage axis used in Mutoh roll-to-roll printers.

This component plays a critical technical role in the machine's operation. Replacing it restores the equipment's original performance.

Component Function

• Precise carriage position reading
• Metrological positioning reference
• High-precision optical strip
• Critical print quality component

References

OEM Reference: DF-43901

Machine Compatibility

• Mutoh ValueJet 1604
• Mutoh ValueJet 1618
• Mutoh ValueJet 1624
• Mutoh ValueJet 1638

Important Technical Information

• Type : linear encoder strip (T-fence) for carriage axis
• OEM reference : DF-43901
• Brand : Mutoh
• Weight : 0.1 kg

Possible Symptoms in Case of Failure

• Carriage position errors
• Irregular print bands
• Encoder error reported
• Visibly scratched or ink-stained strip
