3010113576 - Manifold Thermostat Cable

3010113576 – Manifold thermostat cable (Cable Thermostat Manifold) – Canon Océ Arizona

The 3010113576 manifold thermostat cable (Cable Thermostat Manifold) is fitted to Canon Océ Arizona 6160/6170 XTS and Fujifilm Acuity F66/F67 printers.

It connects the manifold thermostat/temperature sensor to the control board, transmits the temperature information (and/or the thermal cut-out signal), takes part in the thermal safety by cutting the supply in case of detected overheating and ensures the electrical continuity between the manifold and the management unit.

Technical specifications

• OEM reference: 3010113576
• Manufacturer: Canon Océ
• Part type: Manifold thermostat cable
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 61xx
• Fujifilm Acuity

Function

• Connects the manifold thermostat/sensor to the control board
• Transmits the temperature information and the thermal cut-out signal
• Takes part in the thermal safety by cutting the supply on overheating
• Ensures the electrical continuity between the manifold and the management unit

Signs of wear

• Manifold temperature poorly detected
• Thermal errors
• Safety cut-outs
• Faulty electrical continuity

Replacing this part restores the machine to proper working order.
