High-Voltage IDC Ribbon Cable 30P1 310L – Roland AJ-1000 (1000000616)

The Cable-Card 30P1 310L BB High-V (1000000616) is a shielded high-voltage IDC ribbon cable for the Roland AJ-1000 large-format printer. It links the carriage to the mainboard and carries signals between the electronic boards.

A genuine Roland part that restores reliable board-to-board communication; the shielded design resists interference.

Technical specifications

• OEM reference: 1000000616
• Manufacturer: Roland
• Part type: High-voltage IDC ribbon cable (30-pin)
• Designation: 30P1 310L BB High-V
• Connector: Secured IDC
• Machine: Roland AJ-1000
• Shipping: Shipped ready to install

Compatibility & use

• Roland AJ

Function

• Transmit signals between the electronic boards
• Link the carriage to the mainboard
• Shield the high-voltage lines against interference
• Provide a secured IDC connection

Signs of wear

• Board-to-board communication errors
• Intermittent carriage cut-out
• Erratic panel display
• Random failures during printing

Genuine Roland spare part, ready to fit.
