E300644 - FFC 160 Cutter Assembly

Cutter FFC 160 Assy (17-pin) Mimaki CJV30-160 – E300644

The cutter FFC (Cutter FFC 160 Assy, E300644) is the flat flexible cable of the cutting system on the Mimaki CJV30-160 print-and-cut plotter.

It links the cutter driver board (CN3) to the cutter slider board (CN1), carrying the blade command signals.

Technical specifications

• OEM reference: E300644
• Manufacturer: Mimaki
• Part type: Cutter FFC (17-pin flat flexible cable)
• Pins / width: 17-pin, 18 mm
• Length: 3 m
• Shipping: Shipped ready to install

Compatibility & use

• Mimaki CJV30

Function

• Cable / harness linking components in the machine
• Transmits power, signals or data
• Part to replace if damaged

Signs of wear

• Cutting errors or no cut performed
• Irregular or incomplete cuts on the media
• Intermittent cutter-module faults
• Cutting-system error messages

Replacing this part restores the machine to proper working order.
