M011425 – JV33 Main PCB Assembly for Mimaki

The JV33 Main PCB Assy – reference M011425 is the main electronic board used in Mimaki JV33 series printers.

This board provides central management of the machine's electronic system and coordinates the operation of the various components: motors, sensors, secondary boards and print heads.

This is an original Mimaki part (reference M011425) replacing the previous references E104853, E105997 and E106578.

⚠️ This main board is not compatible with the Mimaki JV33BS printer, which requires the M011426 motherboard.

Main board function

• Management of the printer's electronic system
• Communication between internal modules
• Control of motors and sensors
• Data transmission to print heads

Technical information

• Main reference: M011425
• Replaced references: E104853, E105997, E106578
• Name: JV33 Main PCB Assy
• Type: Main circuit board
• Part: Original Mimaki

Machine compatibility

Mimaki JV33 Series

• Mimaki JV33-130
• Mimaki JV33-160

⚠️ Not compatible with Mimaki JV33BS (required card: M011426).

Possible symptoms in case of failure

• Machine start-up problems
• Electronic errors
• Malfunction of several modules
• Loss of communication between components

Replacing the main board restores stable operation of the electronic system and ensures the printer functions correctly.
