3010120831 – PBA printhead control board

3010120831 – Printhead control board (PBA Printhead Control Board) – Canon Océ Arizona 6100 / Fujifilm Acuity F

The 3010120831 printhead control board (PBA Printhead Control Board) is a peripheral electronic board dedicated to the management and driving of the printheads on the Canon Océ Arizona 6100 and Fujifilm Acuity F industrial printers.

It plays a central role in the communication between the printheads, the main electronics and the ink supply, ensuring a stable, precise and synchronised printing. A failing board causes head errors or a full machine stop.

Technical specifications

• OEM reference: 3010120831
• Manufacturer: Canon Océ
• Part type: 100% original Océ
• Associated reference: 3010115403
• Type: PBA (Printed Board Assembly) – printhead control
• Compatible machines: Océ Arizona 6100, Fujifilm Acuity F
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 61xx
• Fujifilm Acuity

Function

• Controls and drives the printheads
• Manages the print and synchronisation signals
• Interfaces the heads with the machine electronics
• Contributes to the print quality, stability and reliability

Signs of wear

• Heads not or poorly driven
• Missing areas or lines in print
• Loss of communication with the heads
• Machine errors or full stop

Replacing this part restores the machine to proper working order.
