KEYBOARD ASSY - E106244

Ref: 20-MIM105-o

-50%

E106244 keyboard board 3042LC – Mimaki | DG Spare Parts

✔️ Type: Keyboard board
✔️ OEM ref: E106244
✔️ Handles the electronic control of the keyboard sub-system
✔️ Compatible: Mimaki CF, Mimaki CFL, Mimaki JFX200 (+2 series)
✔️ Brand: Mimaki

~~Regular price: €317.00~~

€158.50 Save 50%

VAT excluded

New or refurbished at the best price
Fast shipping within 24 hours
Worldwide delivery

Rate us on

Product description

E106244 – Keyboard board (Keyboard 3042LC PCB) – Mimaki flatbed

The E106244 keyboard board (Keyboard 3042LC PCB Assy) is used in Mimaki flatbed printers.

It is also compatible with the reference E106647, used on several Mimaki models. It handles the electronic control of the keyboard sub-system and communicates with the plotter mainboard. A failing board leaves the panel unresponsive.

Technical specifications

OEM reference: E106244
Manufacturer: Mimaki
Part type: Keyboard board
Compatible reference: E106647
Shipping: Shipped ready to install

Compatibility & use

Mimaki CF
Mimaki CFL
Mimaki JFX200
Mimaki JFX500
Mimaki UJF

Function

Handles the electronic control of the keyboard sub-system
Communicates with the plotter mainboard
Processes the command and diagnostic signals

Signs of wear

System error or error code on the control panel
Associated sub-system no longer responds
Erratic machine behaviour
Loss of communication with the mainboard

Replacing this part restores the machine to proper working order.

♻️ DG Spare Parts – European specialist in spare parts for large-format printers and plotters.

Compatibility

Compatible with Mimaki®	Mimaki CF-0912Mimaki CF-1215Mimaki CF-1218Mimaki CFL-605RTMimaki JFX200-2513Mimaki JFX500-2131Mimaki UJF-3042Mimaki UJF-3042FXMimaki UJF-3042HGMimaki UJF-6042
