E107263 - Mark sensor PCB assy

E107263 – Mark sensor PCB – Mimaki

The E107263 mark sensor board (Mark Sensor PCB Assy) is fitted to Mimaki cutting printers.

It optically detects the register/cut marks printed on the media for accurate cutting alignment, measures the media width (built-in width sensor), sends the detection signal to the main board to drive the carriage, and includes an LED pointer for manual sensor-position adjustment. A failing board upsets mark detection.

Technical specifications

• OEM reference: E107263
• Manufacturer: Mimaki
• Part type: Mark sensor PCB
• Shipping: Shipped ready to install

Compatibility & use

• Mimaki CG
• Mimaki CJV150
• Mimaki JV150
• Mimaki JV300
• Mimaki TS300P
• Mimaki Tx300P
• Mimaki UCJV150
• Mimaki UCJV300

Function

• Optically detects the register/cut marks printed on the media for accurate cutting alignment
• Measures the media width (built-in width sensor on the same board)
• Sends the detection signal to the main board to drive the carriage position during cutting
• Includes an LED pointer for manual sensor-position adjustment

Signs of wear

• Cut marks not detected
• Offset cutting
• Media width poorly detected
• Positioning errors

Replacing this part restores the machine to proper working order.

♻️ DG Spare Parts – European specialist in spare parts for large-format printers and plotters.
