Blade Summa 500-9803 - compatible

Compatible Blade Summa 500-9803 (Carbide 60°) Diager

The Diager blade compatible with the Summa 500-9803 (Diager DF-DIA-113) is a double-edge solid-carbide blade for Summa cutting tables, also compatible with Esko BLD-DF113 and Blackman & White BW113.

Its 60° angle gives less overcut and a sharp tip for deep passes on thick vinyl, PVC, cardboard and banner (Ap 6.9 mm).

Product details

• Type: Compatible carbide double-edge blade (Summa 500-9803 / DF-DIA-113, 60°)
• Manufacturer: Diager
• Angle / max depth: 60°, Ap 6.9 mm
• Equivalent: Diager DF-DIA-113 / Esko BLD-DF113 / BW113
• Shipping: In stock, shipped from Europe

Machine compatibility

• Summa F1432
• Summa F1612
• Summa F1832
• Summa F3220
• Summa F3232

Key benefits

• Double-edge solid-carbide blade (60°)
• Deep pass on thick vinyl, PVC and cardboard
• Cost-effective alternative to the OEM Summa 500-9803

Practical information

• Ragged, torn or irregular cut edges
• Incomplete cut through the material
• Higher cutting pressure needed
• Blunt blade — renew

Cost-effective alternative to the OEM Summa 500-9803 blade.
