22635116 - Teflon Tape Pad Cutter

22635116 – Teflon cutting protection strip (Pad Cutter, 1500 mm x 8 mm) – Roland CJ-540 / SC-540 / XC-540

The 22635116 Teflon cutting protection strip (Pad Cutter) is the PTFE strip stuck on the cutting bed of the Roland CJ-540, SC-540, SC-545EX and XC-540 print/cut machines.

It protects the bed surface from the blade cuts during the contour cutting: the Teflon absorbs the blade penetration without blunting it and prevents the knife from scoring the metal bed. A strip in good condition ensures a clean, even cut across the whole media width. It is a self-adhesive genuine Roland DG part, 1500 mm long and 8 mm wide, to replace during preventive maintenance or when deep wear marks appear.

Technical specifications

• OEM reference: 22635116
• Manufacturer: Roland
• Part type: Teflon (PTFE) cutting protection strip (wear part)
• Type: Teflon protection strip (Pad Cutter)
• Material: Teflon (PTFE)
• Length: 1500 mm
• Width: 8 mm
• Mounting: Self-adhesive
• Origin: Genuine Roland DG OEM part
• Shipping: Shipped ready to install

Compatibility & use

• Roland CJ
• Roland SC
• Roland XC

Function

• Protects the metal bed from the cutting blade
• Absorbs the knife penetration without blunting the blade
• Keeps a constant cutting pressure across the media width
• Ensures a clean and accurate contour cut
• Extends the blade life with a soft cutting surface

Signs of wear

• Incomplete or irregular cut on some media areas
• Deep grooves on the Teflon strip surface
• Blade scoring the metal bed (scratching noise)
• Premature cutting blade wear
• Burrs or vinyl tearing instead of a clean cut

Replacing this part restores the machine to proper working order.
