3010112660 - Arizona 550 F/S Print Head Kit (Toshiba CE2)

3010112660 – Toshiba CE2 printhead (reconditioned) – Canon Arizona 550

The Toshiba CE2 printhead kit (ref. 3010112660) is the main print component of the Canon Arizona 550GT and 550XT flatbed printers.

It deposits the ink drops precisely on the media via a multi-greyscale piezoelectric technology. Based on a 16-greyscale micro-piezo technology, it modulates the drop volume from 6 to 90 picolitres to render both fine gradients and dense fills. With 636 active nozzles and an 84.5 μm pitch, the 300 dpi native resolution ensures a precise, even output across the 53.7 mm print swath.

Compatible with oil-based pigment inks and UV-curing pigment inks. This reconditioned head is stored in a suitable preservation liquid. A priming procedure is mandatory before use.

Technical specifications

• OEM reference: 3010112660
• Manufacturer: Canon Océ
• Part type: Printhead (Toshiba CE2, reconditioned)
• OEM references: 3010112660 / 3010110596 / 3010110416 / 3010109461
• Technology: Micro-piezo multi-greyscale (up to 16 levels)
• Active nozzles: 636
• Print swath width: 53.7 mm
• Nozzle pitch: 84.5 μm
• Native resolution: 300 dpi
• Drop volume: 6 – 90 pl
• Typical firing frequency: 2.8 – 28 kHz
• Dimensions: 85 x 74 x 33 mm
• Weight: 174 g
• Ink compatibility: Oil-based pigment ink – UV-curing pigment ink
• Available grades: Perfect: 0-2 missing nozzles / Good: 3-5 / Correct: 6-10
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 5xx
• Fujifilm Acuity

Function

• Jets the ink drops onto the media at the defined resolution (300 dpi native)
• Modulates the drop volume (6 to 90 pl) to manage half-tones and fills
• Handles the greyscale rendering (up to 16 levels) for precise colour transitions
• Ensures even deposit across the 53.7 mm swath with an 84.5 μm pitch
• Ensures compatibility with UV-curing and oil-based pigment inks

Signs of wear

• Horizontal banding or recurring white lines (missing nozzles)
• Incomplete nozzle test: deflected, weak or missing nozzles
• Loss of saturation or colour accuracy on fills
• Ink leaks at the head or uneven deposit on the media
• Uneven greyscale gradient – loss of fineness in transitions

Supplied reconditioned and stored in a suitable preservation liquid — follow the priming procedure before use. We cannot guarantee it as new; each head is graded by missing-nozzle count (Perfect / Good / Correct).
