M0E29-67092 - Substrate loading wedge

Substrate load spacer

The substrate load spacer (Media Load Spacer), part number M0E29-67092, is a component of the substrate input/output system in HP Latex 560 and 570 printers.

This part plays a critical technical role in the machine’s operation. Replacing it restores the equipment to its original performance.

Component function

• Used when loading the
substrate roll• Helps to position the media correctly in the
feed system• Ensures the media is loaded straight and aligned•
Helps to secure the media before it enters the machine

Part Numbers

OEM part number: M0E29-67092
HP designations: Substrate load spacer / Media Load Spacer

Machine compatibility

• HP Latex
560• HP Latex 570

Important technical information

• Type: Substrate load spacer•
OEM part number:
M0E29-67092• Manufacturer:
HP• Area: Substrate input/output system•
Application: HP Latex 500 series roll-fed printers (64")

Possible symptoms in the event of a fault

• Difficulty feeding the media or media feeding at an angle•
Misalignment of the substrate at the feed point•
Spacer lost, broken or
warped• Creases or jams when the media is fed
