45077361 - SMRZ Seal SAC Ink Weight Sensor Coupling

45077361 – Ink weight sensor coupling (Coupling, SMRZ Seal SAC) – EFI Vutek QS/GS

The 45077361 ink weight sensor coupling (SMRZ Seal SAC) is a component of the ink-consumption weighing and monitoring system of the EFI Vutek QS and GS large-format printers.

It ensures the tight mechanical junction between the ink weight sensor and the UV ink supply circuit, with an integrated SAC seal that prevents leaks under vibration or pressure changes. A worn coupling causes wrong ink readings and leaks.

Technical specifications

• OEM reference: 45077361
• Manufacturer: EFI Vutek
• Part type: Original OEM EFI Vutek
• Type: Coupling – ink weight sensor connection
• Seal: SMRZ Seal SAC (Seal Assembly Coupling)
• Material: Technical polymer resistant to UV inks
• Use: Ink weight measuring system – UV supply circuit
• Shipping: Shipped ready to install

Compatibility & use

• VUTEK GS2000
• VUTEk GS2000 Pro
• VUTEk GS2000LX
• VUTEk GS2000LX Pro
• VUTEK GS3200
• VUTEK GS3250 Pro
• VUTEK GS3250LX
• VUTEK GS3250LX Pro
• VUTEK GS3250LXr Pro
• VUTEK GS3250r
• VUTEK GS5000r
• VUTEk H2000 UltraDrop
• VUTEK HS100 Pro
• VUTEK PressVu UV 3xx
• VUTEk QS2 Pro
• VUTEk QS3 Pro
• VUTEk QS220
• VUTEk QS2000
• VUTEk QS3200
• VUTEk QS3200r
• VUTEk QS3220
• VUTEk QS3250r
• VUTEK TX3250r

Function

• Connects the ink weight sensor to the UV ink supply circuit
• Ensures the tightness of the junction via the integrated SMRZ SAC seal
• Allows the precise weighing of the ink consumption for level management
• Keeps the reliability of the ink monitoring to avoid production breaks

Signs of wear

• Wrong or inconsistent ink level readings
• UV ink leaks at the sensor connection
• Ink sensor alarms or error messages
• Unexpected stops from false low-ink alerts

Replacing this part restores the machine to proper working order.
