3010112167 - UV lamp filter compatible with Arizona 61xx (2 pcs, frameless)

UV lamp dust filter (2 pcs, frameless) – Canon Océ Arizona 61xx – 3010112167

The compatible UV lamp dust filter media 3010112167 (3010117472) is fitted to the UV lamp module of the Canon Océ Arizona 61xx series. It traps dust drawn in by the module’s ventilation system, helping to keep the UV system clean and maintain its performance.

This pack of 2 filters is a compatible replacement for the original part, which is now difficult to source: the filter media is cut to the dimensions of the original filter, using a filter fabric suitable for this purpose. It provides equivalent filtration once fitted into the machine’s frame.

Sold without the plastic frame: the filter media fits into the existing frame, replacing the old fabric. The original frame is retained and reused.

Technical specifications

• OEM part number replaced: 3010112167 (3010117472)
• Machine manufacturer: Canon Océ
• Part type: UV lamp dust filter (dust filter), compatible consumable
• Area affected: UV lamp module – cooling air filtration
• Packaging: Set of 2 pre-cut filters
• Plastic frame: Not supplied – reuse the machine’s original frame
• Delivery: Filter media ready to fit into the existing frame
• Application: UV flatbed printer – UV lamp module maintenance

Compatibility and use

• Canon Océ Arizona 6160 XTS
• Canon Océ Arizona 6170 XTS
• Fujifilm Acuity F66
• Fujifilm Acuity F67

Function

• Traps dust before it enters the UV lamp module
• Keeps the lamp and reflector clean
• Maintains a proper cooling airflow over the UV module
• A maintenance consumable to be replaced regularly, at each preventive maintenance service

Possible symptoms of wear

• Clogged, soiled or torn filter
• Visible dust on the lamp or UV reflector
• Abnormal heating of the UV lamp module
• Reduced curing power (incomplete UV curing)

Regular replacement of the filter media maintains the cooling and cleanliness of the UV module and extends the lamp’s service life.
