P7042-A – Industrial limit switch (Switch Limit Industrial, Omron D4N-112G) – VUTEk

The P7042-A industrial limit switch (Switch Limit Industrial, Omron D4N-112G with adjustable roller lever) is fitted to many EFI VUTEk UV large-format printers (QS2000, UltraVu II 3360, PressVu UV, QS3 Pro, QS3250r, UltraVu 150).

It detects a mechanical position and switches the control circuit. A failing switch leaves the end-of-travel position undetected.

Technical specifications

• OEM reference: P7042-A
• Manufacturer: Vutek (Efi)
• Part type: Industrial limit switch (Omron D4N-112G)
• Switch: Omron D4N-112G
• Actuator: Adjustable roller lever
• Contacts: 1 NO + 1 NC (AC-15 3 A / 240 V; DC-13 0.27 A / 250 V)
• Protection: IP67
• Shipping: Shipped ready to install

Compatibility & use

• VUTEK PressVu UV 1xx
• VUTEK PressVu UV 2xx
• VUTEK PressVu UV 3xx
• VUTEk QS3 Pro
• VUTEk QS2000
• VUTEk QS3250r
• VUTEK UltraVu 1xx
• VUTEK UltraVu II 33xx

Function

• Detects an end-of-travel position or the presence of a moving element
• The adjustable roller lever actuates the switching mechanism
• Switches the contacts (1 NO + 1 NC) to signal the position to the system
• Secures or synchronises a movement (carriage, cover, axis) depending on the mounting

Signs of wear

• End-of-travel position not detected: movement not stopped or error
• Machine locked in safety or position message
• Contact no longer switching (wear, oxidation) or intermittent
• Lever or roller broken, seized or out of adjustment

Replacing this part restores the machine to proper working order.
