Q1253-60024 - Discharge solenoid valve cable (APS)

RELIEF VALVE CABLE

The relief valve cable (part number Q1253-60024) connects the relief solenoid valve of the air pressure system (APS) to the circuit board of the HP Latex 560 and 570 printers.

It supplies the solenoid valve with 24 V and enables the machine to control it. Replacing it restores control of the valve when the connection is severed, crimped or damaged.

Component function

• Supplies power to the air pressure system (APS)
relief solenoid valve• Enables the machine to control the opening and closing of the
valve• Provides the electrical connection between the valve and the circuit board•
Plays a part in the air system’s pressurisation and depressurisation cycle

Part Numbers

OEM part number: Q1253-60024

Machine compatibility

• HP Latex
560• HP Latex 570

Important technical information

• Type: discharge solenoid valve cable (APS)
• OEM part number:
Q1253-60024• Origin: genuine HP part (OEM)

Possible symptoms in the event of a fault

• System error: 24 V power supply fault (12.7:10)
• Failure of the air pressure system (APS)
diagnostic test•
Abnormal pressurisation or depressurisation of the air system• Intermittent valve operation (loose connection, damaged cable)
