1000013163 - Cut-Carriage Cable-Card 12P1 2950L BB HIGH-V LEC-540

1000013163 – Cut-carriage FFC flat cable 12-pin 295 cm High-V (Cut-Carriage Cable-Card 12P1 2950L BB High-V) – Roland LEC-540 / XR-640

The 1000013163 cut-carriage flat cable (Cut-Carriage Cable-Card 12P1 2950L BB High-V, FFC 12-pin, 295 cm) is fitted to Roland LEC-540 and XR-640 printers.

It carries the power and the signals to the cutting carriage. A damaged cable causes signal loss and cutter faults.

Technical specifications

• OEM reference: 1000013163
• Manufacturer: Roland
• Part type: Cut-carriage FFC flat cable (12-pin, 295 cm, High-V)
• Shipping: Shipped ready to install

Compatibility & use

• Roland LEC
• Roland XR

Function

• Transmits the power and/or the signals between two parts
• Ensures a reliable electrical link of the circuit
• Key component of the internal wiring of the machine

Signs of wear

• Part not powered or not driven
• Poor contacts or signal loss
• Intermittent cut-outs
• Communication errors

Replacing this part restores the machine to proper working order.
