HD3545 Peripheral Board - 3010117478

3010117478 – Peripheral board (HD3545 Peripheral Board) – Canon Océ Arizona

The 3010117478 peripheral board (HD3545 Peripheral Board) is fitted to Canon Océ Arizona 550 and Fujifilm Acuity printers.

It manages the peripherals and the inputs/outputs of the machine and provides the link with the control board. A failing board leaves the sub-system undriven.

Technical specifications

• OEM reference: 3010117478
• Manufacturer: Canon Océ
• Part type: Peripheral board
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 5xx
• Fujifilm Acuity

Function

• Manages the peripherals and the inputs/outputs
• Relays the signals of the connected parts
• Provides the link with the control board

Signs of wear

• Sub-system not driven
• Electronic errors
• Loss of internal communication
• Erratic behaviour or machine stops

Replacing this part restores the machine to proper working order.
