2174036 - BOARD ASSY PANEL

2174036 – Control panel board (Board Assy Panel) – Epson SureColor F / P / S series

The 2174036 control panel board (Board Assy Panel) is fitted to many Epson SureColor SC-F9300-F9380, SC-P10000-P20080 and SC-S40600-S80680 printers.

It manages the electronics of the operator panel and passes the commands to the main board. A failing board leaves the panel unresponsive.

Technical specifications

• OEM reference: 2174036
• Manufacturer: Epson
• Part type: Control panel board (PCB)
• Shipping: Shipped ready to install

Compatibility & use

• Epson SureColor SC-F9300
• Epson SureColor SC-F9330
• Epson SureColor SC-F9340
• Epson SureColor SC-F9350
• Epson SureColor SC-F9360
• Epson SureColor SC-F9370
• Epson SureColor SC-F9380
• Epson SureColor SC-P10000
• Epson SureColor SC-P10050
• Epson SureColor SC-P10070
• Epson SureColor SC-P10080
• Epson SureColor SC-P20000
• Epson SureColor SC-P20050
• Epson SureColor SC-P20070
• Epson SureColor SC-P20080
• Epson SureColor SC-S40600
• Epson SureColor SC-S40610
• Epson SureColor SC-S40650
• Epson SureColor SC-S40670
• Epson SureColor SC-S40680
• Epson SureColor SC-S60600
• Epson SureColor SC-S60610
• Epson SureColor SC-S60650
• Epson SureColor SC-S60670
• Epson SureColor SC-S60680
• Epson SureColor SC-S80600
• Epson SureColor SC-S80610
• Epson SureColor SC-S80650
• Epson SureColor SC-S80670
• Epson SureColor SC-S80680

Function

• Provides the operator control interface
• Displays the status and allows the operating of the machine
• Passes the commands to the electronics

Signs of wear

• Sub-system not driven
• Electronic errors
• Loss of internal communication
• Erratic behaviour or machine stops

Replacing this part restores the machine to proper working order.
