Blade Tangentielle Carbide Diager 390-DIA-560 – Summa 390-560

The tangential blade carbide Diager 390-DIA-560 (ref. Summa 390-560) is ae cutting blade designed for the outils tangentiels of the Summa plotters. It ensures a cutting half-cut and full-cut of the vinyls adhésifs with a contrôle précis of the profondeur, for a weeding facile and of the coupes nettes.

With a angle of cut of 40° – intermédiaire between the 390-DIA-534 (36°) and the 390-DIA-550 (60°) – the 390-DIA-560 offers a bon équilibre between surcoupe and stabilité géométrique. Its profondeur of cut of 1 mm the positionne for the vinyls standards and supports of grammage moyen, couvrant the great majorité of the applications courantes on Summa plotters.

With a length of 31 mm and a Ø of 2,5 mm, the 390-DIA-560 prend in charge adhesive vinyl, réfléchissant, fenêtre, bannière PVC, material magnétique and polyester fabric.

Technical specifications

• Diager reference : 390-DIA-560 (ancienne ref. 32138)
• Summa reference : 390-560
• Manufacturer : Diager Industrie
• Type : Tangential blade – carbide monobloc
• Diamètre of tige (Ø) : 2,5 mm
• Cutting angle : 40°
• Max cutting depth (Ap) : 1 mm
• Length totale : 31 mm
• Mode of cut : Mi-chair and full-cut
• Application : Cutting polyvalente of vinyls adhésifs on Summa plotters

Compatibility and use

• Plotters of cutting tangentiels Summa – tool reference 390-560

Function

• Cutting half-cut and full-cut of the vinyls adhésifs standards
• Cut of vinyl réfléchissant, of fenêtre and of material of sablage
• Cutting of bannières in PVC adhésif and of materials magnétiques
• Cut of tissus polyester with contrôle précis of the profondeur
• Application polyvalente on the majorité of the supports courants of the Summa plotters

Possible symptoms of wear

• Cutting half-cut incomplète rendant l'weeding difficult
• Perçage of the liner of support during of the coupes full-cut
• Bords irréguliers or frayed on vinyl réfléchissant and bannière PVC
• Profondeur of cut instable on supports of grammage variable
• Dégradation of the precision in tight curves

The replacement of the blade 390-DIA-560 restaure the performances of cutting tangentielle and guarantees a weeding propre and rapide on all of the vinyls traités by the Summa plotters.
