Blade Summa 391-360 - compatible

Blade Traînante Carbide Diager 391-DIA-360 – Summa 391-360

The drag blade carbide Diager 391-DIA-360 (ref. Summa 391-360) is ae cutting blade rapide and precise à tige Ø1,5 mm, designed for the plotters of cutting Summa. Dédiée à the cutting half-cut on materials fins and légers, it guarantees a weeding facile and propre.

With a offset of 0,45 mm and a angle of 36°, the 391-DIA-360 génère a faible surcoupe for the materials fins. Its profondeur of cut maximale of 0,25 mm ensures a cutting precise of the film adhésif without entailler the liner, condition essentielle for a weeding without arrachement.

By rapport à the 391-DIA-358, the tige more fine (Ø1,5 mm) and the angle more fermé (36°) in font the choix optimal for the vinyls fins and the papers légers on Summa plotters.

Technical specifications

• Diager reference : 391-DIA-360 (ancienne ref. 31532)
• Summa reference : 391-360
• Manufacturer : Diager Industrie
• Type : Drag blade – carbide monobloc
• Diamètre of tige (Ø) : 1,5 mm
• Cutting angle : 36°
• Max cutting depth (Ap) : 0,25 mm
• Length totale : 19 mm
• Offset : 0,45 mm
• Grammage material max. : Less than à 200 g/m²

Compatibility and use

• Plotters of cutting Summa – tool reference 391-360

Function

• Cutting half-cut precise on vinyls fins and légers for weeding facile
• Cut of paper inférieur à 200 g/m² without endommager the support
• Cutting of adhesive vinyl standard and of film of fenêtre
• Cut of materials of sablage with séparation clean liner/film
• Application in outil traînant non motorisé à high speed of cut

Possible symptoms of wear

• Cut half-cut incomplète générant of the difficultés d'weeding
• Perçage of the liner of support in raison d'une pressure of cut excessive
• Bords of cut irréguliers on vinyl fin
• Incapacité à suivre the tight curves with precision
• Profondeur of cut insuffisante malgré a réglage à the valeur nominale

The replacement of the blade 391-DIA-360 restaure the qualité of cutting half-cut on vinyl fin and guarantees a weeding without arrachement on the Summa plotters.
