Blade Zund Z5 - compatible

Blade Zund Z5 – Compatible Diager Industrie

The compatible blade Zund Z5 is a passive tangential knife (drag knife) designed for the cutting of expanded polystyrene, Depron, foam légère and panneaux composites légers on Zund plotters.

The blade Z5 stands out by a angle opening encore more large, adapted to the foams légères à structure alvéolaire like the Depron or the expanded polystyrene. This geometry avoids l'écrasement of the cells of foam and produces a surface of cut lisse without burr.

Used particularly in the modelling, the scenography and the fabrication of formes volumiques légères, the Z5 compatible Zund ensures a cutting propre on the materials expansés up to 5 mm d'thickness.

Technical specifications

• Compatible reference : Zund Z5
• Manufacturer : Diager Industrie
• Blade type : Passive tangential knife (drag knife)
• Tip angle : 120°
• Max cutting thickness : 5 mm
• Recommended materials : Polystyrène expansé, Depron, foam légère alvéolaire
• Compatible module : Zund tangential module (TK, UNI-T)
• Quality : High-precision OEM alternative

Compatibility and use

• Plotters of cutting Zund – all models equipped of the Zund tangential module (TK, UNI-T)
• Compatible with standard Zund tool holders
• Direct replacement of the OEM blade Zund Z5 without system modification

Function

• Cutting propre of the foams légères expansées without écrasement cellulaire
• Cut of the Depron and polystyrene for modélisme, scenography and volumique
• Surface of cut lisse without burr on materials alvéolaires
• Suivi précis of the contours vectoriels on panneaux foam légers

Possible symptoms of wear

• Écrasement or déchirure of the cells of foam in bord of cutting
• Surface of cut rugueuse or dentelée on expanded polystyrene
• Déviation of the tracé on the foams légères à faible cohésion
• Résistance accrue to the passage of the blade nécessitant a pressure excessive

Regular replacement of the blade Zund Z5 ensures cutting quality, reduces material waste and extends the life of the cutting module.

♻️ DG Spare Parts – European specialist in spare parts for wide-format plotters and cutting machines.
