Blade Zund Z3 - compatible

Blade Zund Z3 – Compatible Diager Industrie

The compatible blade Zund Z3 is a passive tangential knife (drag knife) designed for the cutting of solid cardboard, single-face corrugated cardboard and foam board léger on Zund plotters.

L'angle of tip more open of the blade Z3 it allows d'aborder the materials à fibers longues like the solid cardboard or the corrugated cardboard without déviation ni arrachement of surface. Its geometry robust maintient the edge of cut on all the length of the blade.

Used for the work packaging, of packaging and of POS display légère, the blade Z3 compatible Zund ensures a cutting clean of the cardboards up to 3 mm without nécessiter of double passe.

Technical specifications

• Compatible reference : Zund Z3
• Manufacturer : Diager Industrie
• Blade type : Passive tangential knife (drag knife)
• Tip angle : 60°
• Max cutting thickness : 3 mm
• Recommended materials : Cardboard compact, single-face corrugated cardboard, foam board léger
• Compatible module : Zund tangential module (TK, UNI-T)
• Quality : High-precision OEM alternative

Compatibility and use

• Plotters of cutting Zund – all models equipped of the Zund tangential module (TK, UNI-T)
• Compatible with standard Zund tool holders
• Direct replacement of the OEM blade Zund Z3 without system modification

Function

• Cutting clean of the solid cardboard and of the corrugated cardboard léger in a seule passe
• Cut precise for packaging, POS display and prototypes cardboard
• Maintien of the edge of cut on materials à fibers longues without arrachement
• Cutting of contours complexes on cardboard with suivi of vecteur précis

Possible symptoms of wear

• Arrachement or déchirure of the fibers in surface of the cardboard
• Nécessité of doubler the passe for traverser the solid cardboard
• Déviation of the trajectory of cut on the courbes
• Bavures or replis in bord of cutting on corrugated cardboard

Regular replacement of the blade Zund Z3 ensures cutting quality, reduces material waste and extends the life of the cutting module.
