CQ114-67023 - Optical Media Exit Detection Sensor

CQ114-67023 – Media out optical sensor (Media Out Optical Sensor) – HP Scitex FB

The CQ114-67023 media out optical sensor (Media Out Optical Sensor) is fitted to HP Scitex FB500, FB550, FB700, FB750 and FB950 printers.

It optically detects the end of the media (media out) and passes the information to the control board to stop the printing. A failing sensor causes wrong detection.

Technical specifications

• OEM reference: CQ114-67023
• Manufacturer: HP
• Part type: Media out optical sensor
• Shipping: Shipped ready to install

Compatibility & use

• HP Scitex FB500
• HP Scitex FB550
• HP Scitex FB700
• HP Scitex FB750
• HP Scitex FB950

Function

• Optically detects the end of the media (media out)
• Passes the information to the control board
• Contributes to the safety and the running of the print

Signs of wear

• Wrong or missing detection
• Position or media errors
• Unexpected machine stops
• Erratic behaviour

Replacing this part restores the machine to proper working order.
