ZWS10B-24 - 24V 10W switching power supply (TDK-Lambda ZWS10B-24)

24 V / 10 W Power Supply (TDK-Lambda ZWS10B-24) Mimaki CF/CFL – ZWS10B-24

The power supply (TDK-Lambda ZWS10B-24) is a 24 V switching PSU fitted to Mimaki CF and CFL flatbed cutters.

It supplies stabilised 24 V DC to the control circuits, with over-voltage and short-circuit protection.

Technical specifications

• OEM reference: ZWS10B-24
• Manufacturer: Mimaki
• Part type: Switching power supply 24 V / 10 W (TDK-Lambda ZWS10B-24)
• Model: TDK-Lambda ZWS10B-24
• Output: 24 V DC
• Input: 85-265 V AC
• Shipping: Shipped ready to install

Compatibility & use

• Mimaki CF
• Mimaki CFL

Function

• Stabilised 24 V DC supply for the control circuits
• AC-DC conversion with voltage regulation
• Over-voltage and short-circuit protection

Signs of wear

• Control circuits without power
• Unstable or absent output voltage
• Random plotter shutdown
• Faulty power supply

Replacing this part restores the machine to proper working order.
