Pack B4H70-67015 – Cartridge drawers (set of 7)

CARTRIDGE TRAYS

Cartridge trays, part number B4H70-67015, are the cartridge-holding trays for the ink supply station of HP Latex 100, 300 and 500 series printers. Each tray holds one cartridge, locks it in place and ensures it is connected to the ink circuit.

Complete set of 7 trays, one for each colour position: magenta (M), light magenta (LM), light cyan (LC) and cyan (C) on the top row; optimiser (OP), yellow (Y) and black (K) on the bottom row. The trays look very similar but each is specific to its position.

This part plays a critical technical role in the machine’s operation. Replacing it restores the equipment to its original performance.

Component function

• Hold and secure the ink cartridges in the
feed station• Ensure lever locking and precise positioning of the
cartridge• Guarantee proper connection of the cartridge to the
ink circuit• Arranged in two rows: 4 drawers at the top, 3 at the bottom

Part numbers

OEM part number: B4H70-67015

Machine compatibility

• HP Latex
110• HP Latex
115• HP Latex
310• HP Latex
315• HP Latex
330• HP Latex
335• HP Latex
360• HP Latex
365• HP Latex
370• HP Latex
375• HP Latex
560• HP Latex 570

Important technical information

• Type: Ink cartridge trays•
OEM part number:
B4H70-67015• Contents: 7 trays — M, LM, LC, C (top row) and OP, Y, K (bottom row)
• Please note: each tray is specific to its colour position, despite looking very similar•
Installation: removal and refitting via lever and clip, no
tools required• Brand: HP

Possible symptoms in the event of a fault

• Cartridge not detected or
repeated read errors• Drawer no longer locks or
broken lever• Poor contact at the cartridge connection,
ink leaks• Warped drawer or broken clip preventing the cartridge from being fitted
