3010104463 - Fitting Elbow, 1/4OD x 1/8NPT

3010104463 – Elbow fitting 1/4 OD × 1/8 NPT – Canon Océ Arizona

The 3010104463 elbow fitting (Fitting Elbow, 1/4OD x 1/8NPT) is fitted to Canon Océ Arizona and Fujifilm Acuity printers.

It provides a sealed connection between a 1/4" flexible tube and a 1/8 NPT thread on the fluid circuit, allows a change of direction in the ink or air circuit and seals the circuit at the connection point. A worn fitting causes leaks and air ingress.

Technical specifications

• OEM reference: 3010104463
• Manufacturer: Canon Océ
• Part type: Elbow fitting (1/4 OD × 1/8 NPT)
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 2xx
• Canon Océ Arizona 3xx
• Canon Océ Arizona 5xx
• Fujifilm Acuity

Function

• Provides a sealed connection between a 1/4" flexible tube and a 1/8 NPT thread on the fluid circuit
• Allows a change of direction in the ink or air circuit
• Seals the circuit at the connection point

Signs of wear

• Leaks at the fitting
• Air ingress
• Pressure drop
• Unsealed connection

Replacing this part restores the machine to proper working order.

♻️ DG Spare Parts – European specialist in spare parts for large-format printers and plotters.
