M0E29-67031 - Rewinder motor without gears

REWINDER MOTOR WITHOUT GEARS M0E29-67031

The gearless rewinder motor assembly, part number M0E29-67031, is used in HP Latex 560 and 570 printers. This part comprises the metal base plate, the two motors with their brass gears and the encoder module.

Replacing this part restores the rewinder drive in the event of a motor failure. Fast delivery across Europe.

Component function

• Drives the printer’s substrate rewinder•
Two motors mounted on a
metal base plate• Brass pinions mounted on the
motors• Encoder module for rotation monitoring

Part numbers

OEM part number: M0E29-67031

Machine compatibility

• HP Latex
560• HP Latex 570

Important technical information

• Type: gearless take-up motors, on
metal baseplate• OEM part number:
M0E29-67031• Contents: metal mounting plate, 2 motors with brass gears,
encoder module• Machines: HP Latex 560 /
570• Service must be carried out with the machine switched off

Possible symptoms in the event of a fault

• Substrate take-up roller does not rotate or rotates
erratically• Error on the
take-up motor• Abnormal noise or motor
jammed• Substrate wound incorrectly at the output
