DG-41077 - CR Motor Assy

DG-41077 – Carriage motor (CR Motor Assy) – Mutoh Valuejet

The DG-41077 carriage motor (CR Motor Assy) is fitted to many Mutoh Valuejet, Osprey, Viper and Canon Océ CS9160 printers.

It drives the print carriage movement and transmits the torque needed for precise positioning. A failing motor causes offsets and travel errors.

Technical specifications

• OEM reference: DG-41077
• Manufacturer: Mutoh
• Part type: Carriage motor
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ CS9160
• Mutoh Blizzard 65
• Mutoh Blizzard 90
• Mutoh Osprey 1xx
• Mutoh Osprey 75
• Mutoh RJ-8000-50 (Falcon II)
• Mutoh RJ-8000-64 (Falcon II)
• Mutoh RJ-8000-87 (Falcon II)
• Mutoh Rockhopper 3 65
• Mutoh Rockhopper 3 90
• Mutoh Rockhopper 3 Extreme 65
• Mutoh Rockhopper 3 Extreme 90
• Mutoh Rockhopper II-2H
• Mutoh Rockhopper II-4H
• Mutoh Rockhopper II 50
• Mutoh Rockhopper II 64
• Mutoh Rockhopper II 87
• Mutoh Spitfire 1xx
• Mutoh Spitfire 65
• Mutoh Spitfire 90
• Mutoh Valuejet 13xx
• Mutoh Valuejet 16xx
• Mutoh Viper 1xx
• Mutoh Viper 65
• Mutoh Viper 90
• Mutoh Viper TX 1xx
• Mutoh Viper TX 65
• Mutoh Viper TX 90

Function

• Drives the print carriage movement
• Transmits the drive torque to the carriage
• Ensures the synchronisation and accuracy of the movement

Signs of wear

• Axis jammed or jerky
• Print offsets
• Motor noise or jam
• Travel errors

Replacing this part restores the machine to proper working order.
