3010105747 - Disk-Oldham Custom
✔️ Type: Oldham coupling disk
✔️ OEM ref: 3010105747
✔️ Transmits motion between two shafts
✔️ Compatible: Canon Océ Arizona 2xx, Canon Océ Arizona 3xx, Canon Océ Arizona 4xx (+5 series)
✔️ Brand: Canon Océ
-
New or refurbished at the best price
-
Fast shipping within 24 hours
-
Worldwide delivery
Product description
3010105747 – Oldham coupling disk (custom) – Canon Océ Arizona
The 3010105747 Oldham coupling disk is a mechanical component used in the drive system of Canon Océ Arizona large-format printers.
It is part of an Oldham coupling — a mechanism that transmits motion between two shafts while compensating for slight mechanical misalignment. In industrial printers, this component helps keep the movement systems running smoothly and accurately.
Technical specifications
- OEM reference: 3010105747
- Manufacturer: Canon Océ
- Part type: Oldham coupling disk
- Shipping: Shipped ready to install
Compatibility & use
- Canon Océ Arizona 2xx
- Canon Océ Arizona 3xx
- Canon Océ Arizona 4xx
- Canon Océ Arizona 5xx
- Canon Océ Arizona 6xx
- Canon Océ Arizona 12xx
- Canon Océ Arizona 22xx
- Fujifilm Acuity
Function
- Transmits motion between two shafts
- Compensates for mechanical misalignment
- Reduces mechanical stress
- Contributes to the stability of the drive system
Signs of wear
- Abnormal noise in the drive system
- Mechanical vibration
- Uneven movement of some mechanisms
- Wear of the transmission system
Replacing this part restores the machine to proper working order.
♻️ DG Spare Parts – European specialist in spare parts for large-format printers and plotters.
Compatibility
| Compatible with Océ-Canon® | Canon Océ Arizona 1240 GTCanon Océ Arizona 1240 XTCanon Océ Arizona 1260 GTCanon Océ Arizona 1260 XTCanon Océ Arizona 1280 GTCanon Océ Arizona 1280 XTCanon Océ Arizona 200 GTCanon Océ Arizona 2260 GTCanon Océ Arizona 2260 XTCanon Océ Arizona 2280 GTCanon Océ Arizona 2280 XTCanon Océ Arizona 250 GTCanon Océ Arizona 300 GTCanon Océ Arizona 318 GLCanon Océ Arizona 350 GTCanon Océ Arizona 350 XTCanon Océ Arizona 360 GTCanon Océ Arizona 360 XTCanon Océ Arizona 365 GTCanon Océ Arizona 365 XTCanon Océ Arizona 440 GTCanon Océ Arizona 440 XTCanon Océ Arizona 460 GTCanon Océ Arizona 460 XTCanon Océ Arizona 480 GTCanon Océ Arizona 480 XTCanon Océ Arizona 550 GTCanon Océ Arizona 550 XTCanon Océ Arizona 640 GTCanon Océ Arizona 640 XTCanon Océ Arizona 660 GTCanon Océ Arizona 660 XT |
|---|---|
| Compatible with Fujifilm® | Fujifilm Acuity Advance HD 2504Fujifilm Acuity Advance HD 2545Fujifilm Acuity Advance HD 2545 X2Fujifilm Acuity Advance HD 2565Fujifilm Acuity Advance HD 2565 X2Fujifilm Acuity Advance HS HD 3545Fujifilm Acuity Advance HS HD 3545 X2Fujifilm Acuity Advance Select HD4004Fujifilm Acuity Advance Select HD4006Fujifilm Acuity Advance Select HD4008Fujifilm Acuity Advance Select HD4224Fujifilm Acuity Advance Select HD4226Fujifilm Acuity Advance Select HD4228Fujifilm Acuity Advance Select HD5004Fujifilm Acuity Advance Select HD5006Fujifilm Acuity Advance Select HD5224Fujifilm Acuity Advance Select HD5226Fujifilm Acuity Select 24Fujifilm Acuity Select 26Fujifilm Acuity Select 28Fujifilm Acuity Select HS 36Fujifilm Acuity Select HS 38Fujifilm Acuity Select HS X36Fujifilm Acuity Select HS X38Fujifilm Acuity Select X24Fujifilm Acuity Select X26Fujifilm Acuity Select X28 |
