3010117741 - AMS idler shaft

3010117741 – AMS idler tensioner shaft (Idler Shaft AMS) – Canon Océ Arizona 22xx-61xx / Fujifilm Acuity

The 3010117741 AMS idler tensioner shaft (Idler Shaft AMS) is fitted to Canon Océ Arizona 2260/2280 and 6160/6170 XTS and Fujifilm Acuity printers.

It keeps a constant tension and alignment of the transmission and absorbs the play for a precise position return. A worn idler causes noise and belt slip.

Technical specifications

• OEM reference: 3010117741
• Manufacturer: Canon Océ
• Part type: AMS idler tensioner shaft
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 22xx
• Canon Océ Arizona 61xx
• Fujifilm Acuity

Function

• Keeps a constant tension and alignment of the transmission
• Guides and returns the belt of the drive
• Absorbs the play for a precise position return

Signs of wear

• Abnormal noise and vibration on the axis
• Positioning offsets and print defects
• Belt slip or loss of torque
• Bearing / shaft overheating and wear

Replacing this part restores the machine to proper working order.
