21685149 - toothed gear for mechanical transmission

GEAR,H235S20(B8)T2

The GEAR,H235S20(B8)T2 reference 21685149 is a toothed gear for mechanical transmission used in Roland cutting plotters.

This component plays a critical technical role in the machine's operation. Replacing it restores the equipment's original performance.

Component Function

• Motor torque transmission
• Tooth dimensional precision
• Rack module compatibility
• Mechanical drive part

References

OEM Reference: 21685149

Machine Compatibility

• Roland VS-640
• Roland XR-640
• Roland VS-540

Important Technical Information

• Type : toothed gear for mechanical transmission
• OEM reference : 21685149
• Brand : Roland
• Weight : 0.02 kg

Possible Symptoms in Case of Failure

• Tooth skip / clicking
• Irregular media advance
• Abnormal transmission noise
• Visibly chipped teeth
