1000006702 - CABLE-CARD,29P1 256L BB HIGH-V

Cable-Card 29P1 256L BB High-V Roland VS-640 – 1000006702

The Cable-Card (1000006702) is a flat flexible cable (FFC) used in the print-head connection system of some large-format printers.

It carries the signals between the electronic board and the print head, keeping the printing system running precisely. Carriage FFC cables must withstand the repeated carriage movements while keeping a stable data transfer.

Technical specifications

• OEM reference: 1000006702
• Manufacturer: Roland
• Part type: Printhead FFC ribbon cable (29-pin, 256 L)
• Name: Cable-Card 29P1 BB High-V
• Length: 256 mm
• Width: 30 mm
• Pins: 29
• Type: FFC / print-head cable
• Head cable set: 3 x 1000006702 + 1 x 1000006703 (Roland XF-640: 4 x 1000006702)
• Shipping: Shipped ready to install

Compatibility & use

• Roland RA
• Roland RE
• Roland RF
• Roland RT
• Roland VS
• Roland XF

Function

• Connection between the print head and the electronics
• Transmission of the printing signals
• Communication between the main board and the head
• Keeps the printing system stable

Signs of wear

• Loss of communication with the print head
• Missing nozzles or unstable printing
• Print-head errors
• Printing-system malfunction

Replacing the cable restores reliable communication between the print head and the electronic board.
