E101209 - Take-up motor switch assy

E101209 – Take-up motor switch (Take-up Motor Switch Assy) – Mimaki JV2 / JV3 / JV4 / TX2 / UJV

The E101209 take-up motor switch (Take-up Motor Switch Assy) is fitted to Mimaki JV2, JV3, JV4, TX2 and UJV printers.

It detects and controls the state of the media take-up motor. A failing switch leaves the take-up uncontrolled.

Technical specifications

• OEM reference: E101209
• Manufacturer: Mimaki
• Part type: Take-up motor switch
• Shipping: Shipped ready to install

Compatibility & use

• Mimaki JV2
• Mimaki JV3
• Mimaki JV3-75 SP II
• Mimaki JV3-130SP II
• Mimaki JV4
• Mimaki PV
• Mimaki TX2
• Mimaki UJV

Function

• Detects or controls the state of the take-up motor
• Passes the signal to the control
• Contributes to the correct take-up operation

Signs of wear

• Take-up not controlled or poorly detected
• Worn or broken switch
• Poor contacts
• Erratic take-up function

Replacing this part restores the machine to proper working order.
