3010114152 - Cable Interconnect Carriage Motor & Encoder

3010114152 – Carriage motor & encoder interconnect cable (Cable Interconnect Carriage Motor & Encoder) – Canon Océ Arizona 61xx

The 3010114152 carriage motor & encoder interconnect cable (Cable Interconnect Carriage Motor & Encoder) is fitted to Canon Océ Arizona 6160/6170 XTS printers (and Fujifilm Acuity F66/F67).

It links the carriage motor and encoder to the electronics and carries the power and the signals. A damaged cable causes carriage errors.

Technical specifications

• OEM reference: 3010114152
• Manufacturer: Canon Océ
• Part type: Carriage motor & encoder interconnect cable
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 61xx
• Fujifilm Acuity

Function

• Transmits the power and/or the signals between two parts
• Ensures a reliable electrical link of the circuit
• Key component of the internal wiring of the machine

Signs of wear

• Part not powered or not driven
• Poor contacts or signal loss
• Intermittent cut-outs
• Communication errors

Replacing this part restores the machine to proper working order.
