Pack W700461280 - ASSY,CARTRIDGE IC BOARD VP-540 (4pcs + cable)

W700461280 – Cartridge IC boards VP-540, pack of 4 + cable (Pack Assy Cartridge IC Board VP-540) – Roland VP-540

The cartridge reading boards (Pack W700461280, Assy Cartridge IC Board VP-540, 4 pcs + cable) are fitted to Roland VP-540 printers. They read the ink cartridge chips and pass the information to the main board.

The Roland designation "ASSY, CARTRIDGE IC BOARD VP-540" and the compatibility with the SP-300i are confirmed by two independent distributors. The pack includes four cartridge reading boards and their connecting cable.

Technical specifications

• OEM reference: W700461280
• Manufacturer: Roland
• Part type: Cartridge IC boards VP-540 (pack of 4 + cable)
• Manufacturer designation: "ASSY, CARTRIDGE IC BOARD VP-540" (Roland parts list)
• Pack contents: 4 "Cartridge IC Board" boards + 1 cable
• Shipping: Shipped ready to install

Compatibility & use

• Roland SP-300i
• Roland SP-540i
• Roland VP-300
• Roland VP-540

Function

• Reads the chip ("IC") of each ink cartridge and passes its identification to the main board, according to the "CARTRIDGE IC BOARD" designation in the Roland parts list
• Ensures the electronic control of a sub-system
• Passes the signals to the main board
• Acts as an interface between the firmware and the hardware

Signs of wear

• Ink cartridge not recognised or reported as faulty on one or more slots (symptom inferred from the chip-reading function, not documented by a manufacturer error code)
• Sub-system not driven
• Electronic errors
• Loss of internal communication
• Erratic behaviour or machine stops

Replacing this part restores the machine to proper working order.

Equivalent references : 1000002172
