ColorPainter M-64s PCB-ASSY-IPB5-100 - U00130607800

U00130607800 – Electronic board (ColorPainter M-64s PCB-ASSY-IPB5-100) – Oki ColorPainter M-64s

The electronic board (ColorPainter M-64s PCB-ASSY-IPB5-100, U00130607800) is fitted to Oki ColorPainter M-64s printers. It ensures the electronic control of a machine sub-system and passes the signals to the main board.

Its manufacturer designation is "PCB-ASSY-IPB5-100". The OKI IP-6620 maintenance manual (ColorPainter M-64s) links this board to servo errors 2a01 / 2a02, auto-calibration errors 2d00 / 2d01 and error 3010; the troubleshooting procedure asks to check the "CARRIAGE FFC" connectors, as the board acts as an interface to the carriage flat cables.

Technical specifications

• OEM reference: U00130607800
• Manufacturer: Oki
• Part type: Electronic board (PCB-ASSY-IPB5)
• Manufacturer designation: "PCB-ASSY-IPB5-100"
• Machine (OKI designation): ColorPainter M-64s ("IP-6620")
• Connectors: FFC (flat cable) connectors to the carriage ("CARRIAGE FFC")
• Note: The equivalent references U00129205100 and U00129204000 are taken from our data; one source describes them as a "PCB-IPB5" board for the ColorPainter W-64s rather than the M-64s. Check against your machine reference before ordering.
• Shipping: Shipped ready to install

Compatibility & use

• Oki ColorPainter M
• Before any replacement, check the condition and seating of the "CARRIAGE FFC" connectors: this is the first step of the manual's troubleshooting procedure for errors 2a01, 2a02, 2d00, 2d01 and 3010.

Function

• Interface between the main board and the carriage flat cables (FFC) according to the OKI IP-6620 maintenance manual
• Ensures the electronic control of a sub-system
• Passes the signals to the main board
• Acts as an interface between the firmware and the hardware

Signs of wear

• Servo errors 2a01 / 2a02
• Auto-calibration errors 2d00 / 2d01
• Error 3010
• Sub-system not driven
• Electronic errors
• Loss of internal communication
• Erratic behaviour or machine stops

Replacing this part restores the machine to proper working order.

Equivalent references : U00129205100 · U00129204000
