7501901-0001 - UVI-01 - IF PCB

7501901-0001 – UVI-01 interface board (IF PCB) – Agfa Anapurna

The 7501901-0001 interface board (UVI-01 IF PCB) is fitted to Agfa Anapurna printers.

It provides the signal interface between the Head Lift board and the head heaters/sensors, manages the heater control signals (headbase heater and sub ink tank heater), relays the temperature-probe data to the control system and acts as the connection point (J1, J2, J7) between the head-lift module and the heater/sensor cables.

Technical specifications

• OEM reference: 7501901-0001
• Manufacturer: Agfa
• Part type: UVI-01 interface board (IF PCB)
• Connectors: J1, J2, J7
• Shipping: Shipped ready to install

Compatibility & use

• Anapurna H1650i
• Anapurna H2050i
• Anapurna H2500i
• Anapurna H3200i
• Anapurna M2050
• Anapurna M2050i
• Anapurna M2500
• Anapurna M2500i
• Anapurna M2540i
• Anapurna M3200i RTR
• Anapurna Mv
• Anapurna Mw
• Anapurna M²

Function

• Provides the signal interface between the Head Lift board and the head heaters/sensors
• Manages the heater control signals (headbase heater and sub ink tank heater)
• Relays the temperature-probe data (headbase and sub ink tank) to the control system
• Acts as the connection point (J1, J2, J7) between the head-lift module and the heater/sensor cables

Signs of wear

• Unregulated head heating
• Temperatures poorly reported
• Sensor errors
• Head-lift malfunctions

Replacing this part restores the machine to proper working order.
