391-360 - Summa 36° rotating cutting blade – diameter 1.5 mm

391-360 – 36° drag knife (tungsten carbide) – Summa

The 391-360 is the standard genuine Summa 36° drag knife, in tungsten carbide. Its 36° cutting angle is optimised for precise cutting of thin-to-normal vinyls and masking films, including small characters and fine details.

Its 0.45 mm offset geometry ensures accurate path following at each change of direction. The tungsten carbide blade lasts 10 to 50 times longer than an ordinary steel blade, reducing replacement frequency and keeping consistent cut quality over time.

It is used with the standard Summa blade holder ref. 391-332 (now 9TL89-67033). This 391-360 reference is replaced by the new reference 9TL89-67041.

Technical specifications

• OEM reference: 391-360 (replaced by 9TL89-67041)
• Manufacturer: Summa (OEM)
• Part type: Drag knife (36°)
• Cutting angle: 36°
• Diameter: 1.5 mm
• Offset: 0.45 mm
• Material: Tungsten carbide
• Compatible holder: 391-332 / 9TL89-67033
• Note: Replaced by new reference 9TL89-67041
• Use: Thin to normal vinyls, masking films, small characters
• Shipping: Shipped ready to install

Compatibility & use

• SummaCut D60
• SummaCut D60FX
• SummaCut D60R
• SummaCut D60SE
• SummaCut D75R
• SummaCut D120R
• SummaCut D140R
• SummaCut D140SE
• SummaCut D160R
• SummaCut D160SE
• SummaCut D620
• SummaCut D760
• SummaCut D1020
• SummaCut D1220
• Summa S Class S120D
• Summa S Class S140D
• Summa S Class S160D
• SummaSign D610
• SummaSign D750
• SummaSign D1010
• SummaSign D1300
• SummaSign D1400
• SummaSign D1600

Function

• Standard rotating (drag) cutting of thin-to-normal vinyls and masking films
• Accurate path following thanks to the 0.45 mm offset
• Cuts small characters and fine details precisely
• Long life from the tungsten carbide edge

Signs of wear

• Incomplete or uneven cuts on vinyl
• Tearing or pull-out of the media while cutting
• Poor path following on small details or tight curves
• Cutting pressure abnormally high to get a correct result

Replacing this blade regularly keeps cut quality consistent and protects the media.
