Roland Plastic Blade Holder — Ref. XD-CH3

The XD-CH3 blade holder is Roland’s original standard blade holder, made from black plastic, with an adjustable depth tip. It accommodates Roland cutting blades and ensures they are held securely during cutting operations on vinyl, flex, paper and other media. Its adjustable tip allows for fine-tuning of the blade’s penetration depth according to the media used, guaranteeing clean and consistent cuts.

This blade holder is a direct replacement for the XD-CH2 and 22205139 models and is compatible with all Roland cutting plotters and printer-cutters equipped with a cutting module.

Technical specifications

• Part number: XD-CH3
• Replaces: XD-CH2 / 22205139
• Brand: Roland (genuine part)
• Material: Black plastic
• Type: Standard blade holder with adjustable tip
• Adjustment: Adjustable cutting depth

Compatibility

Compatible with all Roland series equipped with a cutting function, including:

• Roland BN-20 / BN2 Series
• Roland VersaCAMM VS Series (VS-300, VS-420, VS-540, VS-640 and i variants)
• Roland VersaCAMM VP Series
• Roland SG-300 / SG-540 / SG2-540
• Roland GS-24 / GX Series
• Roland VG-540 / VG2 Series
• Roland CJ / FJ / SJ / SP / XC / XJ / XR / XF Series
• Roland RA / RE / RS Series
• Roland LEC / LEF / LEJ Series
• Roland CM / CX / PNC / SC Series

Possible symptoms in the event of a fault

• Inaccurate cuts or uncontrolled cutting depth
• Blade moves sideways or vibrates during cutting
• Wear or cracks in the plastic body of the blade holder
• Excessive play in the blade housing
