3010107030 – Gantry Belt for Canon Océ Arizona

Gantry belt – 3010107030

The gantry belt (3010107030) is a key mechanical part of the gantry drive on Canon Océ Arizona large-format printers. It transmits the motor movement to the gantry structure for precise, stable carriage travel across the full table width — essential for positioning accuracy and consistent print quality on UV flatbeds.

Technical specifications

• OEM reference: 3010107030
• Manufacturer: Canon (Océ)
• Part type: Gantry drive belt
• Length: approx. 7490 mm
• Width: approx. 38 mm
• May replace: 3010103685 (Carriage Belt)
• Shipping: Shipped ready to install

Compatibility & use

• Canon Océ Arizona 2xx
• Canon Océ Arizona 3xx
• Canon Océ Arizona 4xx
• Canon Océ Arizona 5xx
• Canon Océ Arizona 6xx
• Canon Océ Arizona 12xx
• Canon Océ Arizona 22xx
• Fujifilm Acuity

Function

• Transmits the motor movement to the gantry
• Ensures precise, regular travel along the axis

Signs of wear

• Print misregistration or misalignment
• Noise during gantry travel
• Visible belt wear
• Irregular axis movement

Replacing this part restores the machine to proper working order.
